Precision Automatic CNC Lathe Machine
Precision automatic CNC lathe is high-precision, high-automation multi-functional machining equipment. Its core is "sliding headstock" machining, where bar stock spindle moves axially, cooperating with live tool turret to achieve multi-process composite cutting. Single clamping completes turning, milling, drilling, tapping, and all other operations, ensuring extremely high coaxiality and positional accuracy. It is especially adept at machining slender long shafts and miniature parts.
Machine integrates automatic bar feeding system, supporting 24/7 unattended continuous production. At micron-level accuracy, it provides high-efficiency solution for high-volume, high-consistency production.
Specifications
|
Model |
0640 |
|
Feeding Method |
Front feeding (cylinder feeding) |
|
Filling Method |
Small guide plate type |
|
Discharge Method |
Pneumatic push feeding |
|
Workpiece Length |
50-200mm |
|
Bed Configuration |
Integral flat bed with linear guideways |
|
Control System |
CNC system + PLC |
|
Spindle Structure |
Front 3 + rear 2 bearings (optional spindle unit) |
|
Spindle Nose |
A2-5 |
|
Spindle Speed |
50-3000 RPM |
|
Broached Through-Hole |
φ40mm (max. bar stock passage diameter) |
|
Clamping Method |
Hollow rotary hydraulic cylinder |
|
Spindle Fixture |
0640 collet chuck (optional hydraulic chuck) |
|
Motor Power |
4 KW/5.5 KW |
|
Tool Holder Type |
Gang tool post (optional electric tool post) |
|
Chip Removal Method |
Right-side chip discharge |
|
X/Z-axis Rapid Traverse Speed X/Z |
15m/min |
|
Maximum X/Z-axis Travel X/Z |
600mm/200mm |
|
Total Machine Weight |
Approx. 1000kg |
|
Overall Dimensions |
1700×1400×1700 (L×W×H) |
Scope of Application
Suitable for complex processes on short shafts, stepped shafts, disc-shaped parts, and tubular components, achieving precision automated machining.
Equipment Manufacturing Process
Through full communication with customer, discuss material, machining method, machine model, cost, and other items. Combine all aspects to develop suitable design solution and quotation for customer.
After customer confirms solution feasibility, sign formal contract. Clearly specify machine model, configuration, payment method, shipping method, and other items in contract.
Customer signs contract and pays 30%-50% of total value as deposit. After receiving deposit, arrange factory production scheduling.
After machine assembly completion, perform final debugging and testing. After passing test, invite customer to factory for on-site machine operation inspection, or accept via video.
After customer passes pre-acceptance, wait for customer to pay machine balance. Upon receipt of payment, pack and ship machine according to contract requirements to delivery location designated by customer.
About Qiyang
Taizhou Qiyang Trading Co., Ltd. is a high-tech enterprise dedicated to the research and development, manufacturing, and sales of automated hardware machinery and precision CNC machine tools. By integrating advanced manufacturing expertise and technological resources from across the industry, the company is committed to providing global clients with high-quality machine tools and professional machining solutions.
FAQ
Q1. Can you send me catalog and price list of all your machines?
A: Yes, our products include hydraulic lathe, CNC lathe, and many other types. Please let us know material size, accuracy requirement, and production volume of parts you need to machine. Based on your requirements, we will recommend 1-2 most suitable models, along with detailed technical solution and targeted quotation.
Q2. What is lowest price for this machine?
A: Machine price depends on specific configuration. Our standard configuration offers strong competitiveness in ensuring long-term stability and accuracy retention. Many customers report that higher machining efficiency and lower failure rate of our equipment bring total cost of ownership below comparable products within 2 years. Would you mind sharing your core requirements and target budget? We will develop most cost-effective solution for you.
