Multi-Axis Milling Machine
Biggest advantage of this machine is completing milling of multiple surfaces on workpiece with single clamping, fundamentally eliminating repeat positioning error caused by multiple clamping, flipping, and realigning. This ensures high perpendicularity, parallelism, and positional accuracy between machined surfaces.
Additionally, machine is equipped with two or more milling power heads, capable of machining surfaces in different directions simultaneously, greatly reducing auxiliary time and cutting travel, significantly improving production efficiency and cycle time for batch production. It is especially suitable for medium to high-volume standardized parts.
Machine features good overall structural rigidity and strong vibration resistance during multi-direction simultaneous cutting, delivering excellent machined surface quality. It is ideal choice for high-efficiency, high-precision batch milling of flat and profiled surfaces.
Specifications
|
Model |
Model 25, Model 32 |
|
Workpiece Length |
20-80 mm (vibratory bowl feeder optional) |
|
Workpiece Diameter |
Φ4-25 mm |
|
Workpiece Shape |
Round |
|
Feeding Method |
Front feeding |
|
Control System |
PLC + hydraulic system |
|
Motor Power |
1.5 KW |
|
Spindle Speed |
1400 RPM |
|
Power Supply |
380V 50Hz (three-phase four-wire) |
|
Indexing Range |
2, 4, 6, 8 divisions |
|
Total Machine Weight |
Approx. 600 kg |
|
Overall Dimensions |
1300×1000×1500 (L×W×H) |
Scope of Application
Suitable for automated tapping of plumbing hardware valve parts and multi-face machining of various long and short shaft parts in batch production.
Equipment Manufacturing Process
Order Intake & Process Assessment
Customer provides workpiece drawing, physical sample, and expected production capacity. Both parties conduct in-depth requirement communication, focusing on interference risk of multi-face simultaneous machining, rigidity requirement, and clamping solution.
Accurate Model Selection & Transparent Quotation
Based on process route, match optimal machine model for customer. Quotation strictly includes: machine tax-inclusive price, standard delivery time, payment method, warranty scope, and wear parts list. Ensure every responsibility is clear, avoiding subsequent commercial disputes from source.
Contract Signing & Responsibility Lock-in
Sign formal purchase contract, specifying acceptance criteria (position accuracy, flatness) and late delivery penalty.
Deposit Confirmation & Production Scheduling
After finance confirms receipt of agreed deposit (30%-50%), issue production process sheet.
Precision Manufacturing & Multi-axis Joint Debugging
Workshop strictly follows process sheet for assembly. After assembly completion, perform timely debugging. Use customer-provided sample for actual test cutting, finely calibrating feed rate and cutting speed.
Final Pre-shipment Inspection & Balance Request (Delivery Firewall)
After machined sample passes inspection, send real video of multi-face machining to customer. After customer confirms equipment accuracy and machining effect meet standard, request customer to pay remaining balance according to contract.
Logistics Shipment & Tracking Feedback
After confirming full payment received, perform professional reinforced packing and shipment. Provide cargo shipping order, driver contact, and logistics tracking number at first opportunity, ensuring customer can track cargo status at any time.
After-sales Closure & Secondary Marketing
After machine arrives at customer facility and installation debugging completes, customer signs debugging acceptance form. We issue full VAT invoice and establish dedicated customer file.
About Qiyang
Taizhou Qiyang Trading Co., Ltd. is a high-tech enterprise dedicated to the research and development, manufacturing, and sales of automated hardware machinery and precision CNC machine tools. By integrating advanced manufacturing expertise and technological resources from across the industry, the company is committed to providing global clients with high-quality machine tools and professional machining solutions.
FAQ
Q1. What is multi-axis milling machine? Main application?
A: Multi-axis milling machine is special purpose / modular machine tool equipped with two or more milling heads (double-sided, three-sided, or four-sided), capable of milling multiple sides of workpiece simultaneously with single clamping. Mainly used for batch multi-face milling of shaft, block, and box-type parts, offering high efficiency and good repeat positioning accuracy.
Q2. What are advantages compared with conventional milling machine?
A: Complete multi-face machining with single clamping, reducing cumulative error from multiple alignment and flipping, improving symmetry / parallelism and production efficiency. Suitable for high-volume production.
Q3. How to select correct multi-axis milling machine model?
A: Please provide workpiece material, machining size (L×W×H), number of sides to mill simultaneously, accuracy requirement, and production capacity. You can also send part drawing to us. We will recommend matching machine model based on your requirement.
