Automatic Feeding CNC Lathe
This machine uses microcomputer programming to control machining process. Servo motor, PLC, or hydraulic system enables automatic bar feeding and clamping. Multiple tool posts perform turning, drilling, and other operations. Core components include CNC system, feeding mechanism (such as oil bath bar feeder, hydraulic push-feed device), and machining spindle. Features include high level of automation, stable machining accuracy, wide applicability, one-shot forming of complex parts, fast processing speed, high efficiency with low energy consumption, and simple operation.
Specifications
|
Model |
0640 |
|
Feeding Method |
Front feeding (cylinder feeding) |
|
Filling Method |
Vibratory bowl feeder (optional elevator) |
|
Discharge Method |
Parts receiver + conveyor belt |
|
Workpiece Length |
10-80mm |
|
Bed Configuration |
Integral 45° slant bed with linear guideways |
|
Control System |
CNC system + PLC |
|
Spindle Structure |
Spindle unit (front 4 + rear 2 bearings) |
|
Spindle Nose |
A2-5 |
|
Spindle Speed |
50-3500 RPM |
|
Broached Through-Hole |
φ40mm (max. bar stock passage diameter) |
|
Clamping Method |
Hollow rotary hydraulic cylinder |
|
Spindle Fixture |
0640 collet chuck (optional hydraulic chuck) |
|
Motor Power |
4 KW/5.5 KW/7.5KW |
|
Tool Holder Type |
Gang tool post (optional servo turret) |
|
Chip Removal Method |
Rear chip discharge |
|
X/Z-axis Rapid Traverse Speed X/Z |
24m/min |
|
Maximum X/Z-axis Travel X/Z |
700mm/350mm |
|
Total Machine Weight |
Approx. 1300kg |
|
Overall Dimensions |
1850×1400×1800 (L×W×H) |
Scope of Application
Suitable for automated, high-precision machining of complex processes on short shafts, stepped shafts, disc-shaped parts, and tubular components.
Equipment Manufacturing Process
Initial contact: Both parties fully communicate to determine machining feasibility, confirm machining method, machine model, feeding method, and various configurations.
Design: Based on communication results, manufacturer designs solution, creates drawings, and finalizes process.
Cooperation: Both parties confirm cooperation intent. Customer is satisfied with design solution and requests formal contract for order placement.
Production: After receiving customer deposit, manufacturer begins production of corresponding equipment.
Debugging: After machine is built, conduct trial run, adjust accuracy, and notify customer for acceptance inspection.
Delivery: After debugging, contact customer for payment of remaining balance. Arrange shipment once balance is paid in full.
About Qiyang
Taizhou Qiyang Trading Co., Ltd. is a high-tech enterprise dedicated to the research and development, manufacturing, and sales of automated hardware machinery and precision CNC machine tools. By integrating advanced manufacturing expertise and technological resources from across the industry, the company is committed to providing global clients with high-quality machine tools and professional machining solutions.
FAQ
Q1. Can this machine process my part?
A: Please provide your product drawing or sample. We will evaluate material, dimensions, processes (such as turning, milling, drilling, tapping), and accuracy requirements to confirm machine compatibility or plan necessary customization for you.
Q2. What do I need to prepare for this machine to run?
A: Typically, you need to provide: ① Stable power supply (e.g., 380V three-phase electricity); ② Clean compressed air (specified pressure and flow rate); ③ Suitable production floor space (size, load capacity, temperature and humidity control); ④ Qualified operator/programmer.
Q3. How long does it take from your shipment to normal production at my site?
A: It depends on shipping distance, site preparation, and commissioning complexity. Typical process: Shipment (1-5 days) → Arrival and positioning (0.5 day) → Installation and wiring (3-5 days) → Debugging and trial production (1-3 days) → Operator training (1-2 days). Total approximately 10-20 working days to achieve production (taking domestic customer as example).
